- AI Motion Detection DVR: Enabling the human & vehicle detection feature to get real time APP push and alerts when motion is detected
- 5-in-1 Hybrid DVR: The digital video recorder supports up to 16pcs TVI/AHD/CVI/CVBS and extra 2 IP cameras. Worry no more for camera signal
- H.265 DVR: Advanced H.265 video compression tech saves up to 80% of storage space compared to H.264 one
- Remote Access DVR: Download ANNKE Vision App to control the DVR via phone, tablet, computer and browser to realize remote access
- All-Around Certificates DVR: Tested by authorized organizations, like UL, CE, HDMI, ANNKE ensures the video stream is secure in data transferring & downloading
DVR Specification:
· Up to 3K high definition live viewing
· Up to 3K Lite recording & playback
· Advanced H.265 Video Compression
· Support TVI/AHD/CVI/CVBS/IPC input. 5 in 1
· Supports iPhone、iPad、Android mobile remote monitoring
· Deep learning based human and vehicle targets classification of Motion Detection 2.0 for all analog channels
· Quick search by object or event type
· Audio via coaxial cable
Video Compression: H.264 /H.264/H.265/H.265
Video Input: 16CH Analog HD/Analog 2CH IP Video (up to 24 channel when IP enhanced mode on)
Video Output: HDMI and VGA Up to 1080P
Audio Input: 1-ch RCA, 16-ch via coaxial cable
Audio Output: 1-ch RCA
Supported Camera Types: "Support HD TVI Input: 3K/5MP@20FPS, 4MP, 3MP, 1080p, 720p;
Support AHD Input: 4MP, 1080p, 720P;
Support CVI Input: 4MP, 1080p, 720P;
Support CVBS Input;
Support IP Video Input：6MP/5MP/4MP/3MP/1080P/720P"
Analog HD Playback Resolution: 3K Lite/5MP Lite/4MP Lite@12fps,1080p/720p@15fps
IPC Playback Resolution: Up to 6MP
Max Playback Channel: 4-ch
Motion Detection 2.0: All analog channels support human and vehicle detection to reduce false alarm
HDD: 1 SATA interface
HDD Capacity: Up to 10TB capacity
